Overview
S7200-8XE1TF-DC, 8 Port 2.5G Unmanaged Ethernet Switch with 1 Port 10G SFP+，Desktop and wall mount, Fanless silent design
Physical Port
- 8-10/100/1000/2500BASE-TX Ethernet RJ45 ports
- 1-1G/2.5G/10GBASE-TX Ethernet SFP+ Interface
Switching
- Backplane bandwidth 64Gbps，Packet forwarding rate 44.64Mpps，MAC address 2k
- Hardware-based 10/100/1000/2500Mbps (half/full duplex)auto-negotiation and auto MDI/MDI-X
- Features Store-and-Forward mode with wire-speed filtering and forwarding rates
- IEEE 802.3x flow control for full duplex operation and back pressure for half duplex operation
Hardware
- High- strength metal case
- Wall mount design
- DC 12V input
- Supports 6KV DC Ethernet ESD protection
- -20 to 55 degrees C operating temperature
- LED indicators for Power,LINK/ACT
Features
8-Port 2.5G Ethernet Connectivity
The S7200-8XE1TF-DC provides 8 high-speed 2.5G Ethernet ports, delivering data transfer rates 2.5 times faster than traditional Gigabit Ethernet. This feature supports seamless streaming, faster downloads, and efficient data sharing, catering to bandwidth-intensive applications. Whether used for gaming, video editing, or high-speed file transfers, these ports enhance overall network performance by preventing bottlenecks. The 2.5G connectivity ensures future-proofing, enabling compatibility with modern devices that require higher speeds for optimal functionality.
1 10G SFP+ Uplink Port
With a 10G SFP+ uplink port, this switch ensures lightning-fast data transfer and efficient uplink capabilities. The 10Gbps port enables seamless integration with high-bandwidth network backbones or additional switches, ideal for demanding applications like data centers, large file transfers, and fast backups. This feature allows businesses to scale their networks while ensuring top-notch performance. It supports fiber-optic connections for extended reach, making it suitable for linking devices across long distances or high-performance environments.
Wire-Speed Forwarding and Low Latency
The S7200-8XE1TF-DC offers wire-speed forwarding, ensuring data packets are transmitted without delays or bottlenecks. This capability is essential for real-time applications such as video conferencing, online gaming, or live streaming. Its low-latency performance reduces delays, ensuring smooth and uninterrupted communication. This combination of speed and responsiveness enhances productivity and user experience, making the switch an excellent choice for high-demand environments that require reliable and quick data transmission.
Plug-and-Play Installation
The plug-and-play design of the S7200-8XE1TF-DC eliminates the need for complex configurations, making it simple and user-friendly. Users can set up the switch by merely connecting their devices and powering it on, making it accessible even to those without technical expertise. This feature is perfect for small businesses or home users looking for a quick network upgrade without the hassle of additional software or settings. It streamlines setup, saving time and reducing deployment costs.
Silent Operation for Noise-Sensitive Environments
Designed with a fanless, silent operation, this switch is ideal for noise-sensitive environments such as offices, libraries, or home workspaces. The absence of fans ensures quiet performance without compromising on reliability or efficiency. This makes the switch suitable for areas where minimizing noise is a priority, providing users with a distraction-free networking experience. The silent operation also extends the product's lifespan by reducing the wear and tear associated with moving parts like fans.
Wall-Mountable Design for Flexible Deployment
The wall-mountable design allows the S7200-8XE1TF-DC to be installed conveniently in spaces with limited room. This flexibility enables users to keep their setups organized and free from clutter, whether in a small office, home workspace, or industrial environment. Wall-mounting also protects the device from accidental knocks or spills, ensuring longevity and reliability. Its compact form factor blends seamlessly into any environment, offering a practical and space-efficient networking solution.
Wide Operating Temperature Range (-20°C to 55°C)
The switch’s ability to operate within a temperature range of -20°C to 55°C makes it suitable for diverse environments, from offices to industrial settings. Whether used in warm indoor setups or colder outdoor deployments, the device delivers consistent and reliable performance. This resilience ensures users can rely on the switch in extreme conditions without worrying about network disruptions, providing a stable and robust networking solution for challenging scenarios.
Connectivity Solutions
8 Port 2.5G Ethernet Switch with 1 Port 10G SFP+ Uplink Connection Solution
Specification
Technical Specifications :
S7200-8XE1TF-DC10M/100M/1G/2.5G RJ45 copper ports :
81G/2.5G/10G SFP+ (fiber) ports :
1Performance Specification :
*Packet buffer memory :
8.2 MbForwarding modes :
Store-and-forwardBandwidth :
64 GbpsPacket forwarding rate :
44.64MppsMAC address database size :
2KJumbo frame support :
9kIEEE Network Protocols :
*Protocols :
• IEEE 802.3 Ethernet • IEEE 802.3u 100BASE-T • IEEE 802.3ab 100BASE-T • IEEE 802.3z 100BASE-X • IEEE 802.3bz 2.5GBASE-T • IEEE 802.3ae 10GBASE-X• IEEE 802.3az Energy Efficient Ethernet (EEE) • IEEE 802.3x Full-Duplex Flow ControlMonitoring :
*LEDs :
YesPer port :
Speed, Link, Activity;Per device :
PowerPhysical Specifications :
*Dimensions (Width * Depth * Height) :
210 x 126 x 28mm (8.27 x 4.96 x 1.1 in)Weight :
0.51 kg (1.12 lb)Power Consumption :
*Max power :
9WIddle power consumption :
5WEnergy Efficient Ethernet (EEE) :
Yes (deactivated by default)Fan :
FanlessEnvironmental Specifications :
*Operating Temperature :
-20° to 50°C (-4° to 122°F)Operating Humidity :
90% maximum relative humidity (RH), non-condensingOperating Altitude :
10,000 ft (3,000 m) maximumStorage Temperature :
-30° to 70°C (-22° to 158°F)Storage Humidity (relative) :
95% maximum relative humidity, non-condensingStorage Altitude :
10,000 ft (3,000 m) maximumElectromagnetic Emissions and Immunity :
*Certifications :
CE mark, commercial； FCC Part 15 Class A, VCCI Class A； Class A EN 55022 (CISPR 22) Class A； Class A C-Tick； EN 55024； CCC； 47 CFR FCC Part 15, SubpartB, Class A ICES-003: 2016 Issue 6, Class A； ANSI C63.4:2014； IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013Safety :
*Safety Certifications :
CB mark, commercial； CSA certified (CSA 22.2 #950)； UL listed (UL 1950)/cUL IEC 950/EN 60950； EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013 IEC 60950-1:2005 ；(ed.2)+A1:2009+A2:2013； AN/NZS 60950.1:2015； CCC (China Compulsory Certificate)Warranty and Support :
*Hardware Limited Warranty :
Limited Lifetime*Technical Support via Phone and Email* :
Limited Lifetime*24x7 Online Chat Technical Support :
Limited Lifetime*Package Contents :
*All models :
8 Port 2.5G Network Switch；Power adapter (localized to region of sale)Business Type :
CommercialBandridth :
2.5G+10GMore Filters :
Unmanaged
Questions & Answers
1. Is the S7200-8XE1TF-DC compatible with both desktop and wall mounting setups?
Yes, the S7200-8XE1TF-DC supports both desktop placement and wall mounting. Its compact, fanless design ensures silent operation, making it ideal for flexible installations in homes, offices, or small workspaces.
2. Does the S7200-8XE1TF-DC require any special setup or configuration?
No, the S7200-8XE1TF-DC is plug-and-play. Simply connect your devices, and it will start operating without any need for technical expertise or complex configurations.
3. Can this 8-port 2.5G unmanaged ethernet switch handle high-bandwidth applications like 4K streaming and gaming?
Yes, with 8 ports of 2.5G and a 10G SFP+ uplink, it supports high-speed data transmission and low-latency performance, making it ideal for 4K streaming, gaming, and other demanding tasks.
4. How does the S7200-8XE1TF-DC ensure reliability in harsh conditions?
This switch operates in temperatures ranging from -20°C to 55°C and features 6KV ESD protection, ensuring stable performance and durability in diverse environments.
5. Is this 8-port 2.5G unmanaged ethernet switch energy-efficient and suitable for long-term use?
Yes, the fanless design ensures energy efficiency and silent operation. Its robust build and high-performance capabilities make it a future-proof solution for long-term networking needs.
