4 Ports Gigabit Unmanaged PoE+ Switch, with 2-1Gb SFP, 4 PoE+ Ports@65W Power budget, Suppout PoE Extend 250m，Fanless, Desktop or wall-Mount, SP5200-4PGE2GF

gigabit ethernet switch 4 port poe
unmanaged switch 4 port poe
gigabit network switch 4 port poe
gigabit switch 4 port poe

4 Ports Gigabit Unmanaged PoE+ Switch, with 2-1Gb SFP, 4 PoE+ Ports@65W Power budget, Suppout PoE Extend 250m，Fanless, Desktop or wall-Mount, SP5200-4PGE2GF

Inquire Now

Designed for IP Camera/Wireless Access Point

Product Highlights
    • 4-10/100/1000Mbps RJ45 ports with PoE+
    • 2-1.25Gbps mini-GBIC SFP interface
    • 4 ports supporting PoE+ to PD device(Port 1-port4)
    • Complies with IEEE 802.3af/at Power over Ethernet
    • Supports PoE power up to 30 watts for each PoE port，
    • 58-watt PoE budget,65-watt power budget
    • Supports contact discharge of ±4KV DC and air discharge of ±6KV DC for Ethernet ESD protection
    • Backplane bandwidth 24Gbps，Packet forwarding rate 8.93Mpps，MAC address 4k
    • 10-inch Rack-Mount size, 1U height，Internal AC power supply

gigabit 4 ports poe switch with 2sfp authentication

Overview



SP5200-4PGE2GF, 4 Ports Gigabit Unmanaged PoE+ Switch, with 2-1Gb SFP,4 PoE+ Ports@65W power budget, Suppout PoE Extend 250m, Fanless, Desktop-Mount or wall-Mount

The SP5200-4PGE2GF Benchu group’s 4 Port Gigabit Unmanaged PoE+ Switches offers a high speed, High performance and low cost gigabit network solution. The Gigabit PoE Swtiches provides sisteen 30-watt 802.3at PoE+ ports ,2 gigabit SFP uplink.

The SP5200-4PGE2GF  optimizes the installation and power management of network devices such as wireless access points, VoIP phones, and security cameras. It also eliminates time and cost of deployment by integrating power and data switching into one unit and freeing network devices from restrictions of power outlet locations and the additional AC wiring.



Physical Port

  • 4-10/100/1000Mbps Gigabit Ethernet ports with PoE+
  • 2-1.25Gbps mini-GBIC SFP interface



Power over Ethernet

  • 4 ports supporting PoE+ to PD device (Port 1 to port 4)
  • Complies with IEEE 802.3af/at Power over Ethernet
  • Supports PoE Power up to 30 watts for each PoE port
  • 58-watt PoE budget, 65-watt total power budget
  • Auto detects powered device (PD)
  • Supports 25-watt PoE transmit distance of 250m in extend mode
  • Remote power feeding up to 100m in standard mode
  • Circuit protection prevents power interference between ports



Switching

  • Solid performance with non-blocking architecture
  • 24Gbps Backplane bandwidth, 8.93Mpps Switch Throughput，9216 bytes Jumbo Frame
  • supporting 4K MAC addresses
  • Automatic address learning and address aging
  • Hardware-based 10/100/1000Mbps auto-negotiation and auto MDI/MDI-X
  • Flow control for full duplex operation and back pressure for half duplex operation
  • Integrates address look-up engine, supporting 8K absolute MAC addresses
  • Automatic address learning and address aging
  • Supports Energy-Efficient Ethernet (EEE) function (IEEE 802.3az)



Hardware

  • High-strength metal casing.
  • 7-inch Desktop-Mount , wall-Mount, 1U height
  • LED indicators for Power,PoE Working and LINK/ACT
  • Fanless design, Silent Operation
  • Internal AC power supply





Features



Gigabit port and fiber Port Configuration

4 × PoE+ 10/100/1000Mbps RJ45 ports provide up to 30W per port and Power budget of 65W, together with 2 x 1.25G SFP uplink.

gigabit 4 port poe switch with 2 sfp





Enhanced Flexibility and Deployment Options

The SP5200-4PGE2GF 250-meter PoE switch offers enhanced flexibility in network design, accommodating diverse deployment scenarios that are not feasible with standard 100-meter PoE limitations. This flexibility is crucial for applications requiring distant device placement, such as remote surveillance, extended outdoor Wi-Fi coverage, and large-scale IoT sensor networks. By supporting longer distances, the switch allows for strategic device positioning to optimize coverage and performance. This adaptability ensures that network planners can meet specific environmental and operational needs, improving overall network efficiency and effectiveness while supporting a wider range of use cases.

4 Ports gigabit 250meter poe switch



Reliable Performance in Harsh Conditions

PoE switches with a wide temperature range of -20°C to 50°C ensure reliable operation in extreme weather conditions. This capability makes them ideal for environments where temperatures can fluctuate significantly. Their robust design minimizes the risk of failure due to temperature-related stress, ensuring continuous power and data transmission. This reliability is crucial for maintaining network connectivity in critical applications, such as surveillance systems, remote sensors, and outdoor wireless access points, providing peace of mind that the network will remain operational regardless of environmental conditions.



4 port gigabit poe switch wide temperature design







6KV Lightning Protection design Reduced Maintenance Costs

The SP5200-4PGE2GF PoE Switches with 6KV lightning protection require fewer maintenance interventions due to their enhanced resilience against electrical surges. This protection lowers the incidence of surge-related damage, reducing the need for frequent repairs or replacements of damaged equipment. Consequently, maintenance costs are significantly reduced, as less time and resources are spent on addressing surge-related issues.  This reduction in maintenance demands also minimizes network downtime, contributing to overall operational efficiency protecting user investment.



Unmanaged 4 port gigabit poe switch ESD 6KV lightning protection









Connectivity Solutions



Gigabit 4 port PoE switch with 2 SFP Connectivity Solution



4 port gigabit poe+ switches with 2 SFP





Gigabit 4 port PoE switch with 2 SFP Connectivity Solution 2



4 port poe switch with 2 sfp





Specification





  • Technical Specifications :

    SP5200-4PGE2GF

  • 10M/100M/1G RJ45 copper ports :

    4

  • 1.25G SFP (fiber) ports :

    2

  • PoE / PoE+ ports :

    4

  • Power over Ethernet :

    *

  • PoE Standard :

    IEEE 802.3at Power over Ethernet Plus/PSE; Backward compatible with IEEE 802.3af Power over Ethernet

  • PoE Power Supply Type :

    End-span: 1/2 (+), 3/6 (-)

  • PoE Power Output :

    Per port 52V DC, 300mA. max. 15.4 watts (IEEE 802.3af); Per port 52V DC, 600mA. max. 30 watts (IEEE 802.3at)

  • PoE Power Budget :

    58 Watts

  • Number of PDs, 7 watts :

    4

  • Number of PDs, 15 watts :

    4

  • Number of PDs, 30 watts :

    2

  • Performance Specification :

    *

  • Chip :

    Realtek

  • Packet buffer memory :

    1.7 Mb (Dynamically shared across only used ports)

  • Forwarding modes :

    Store-and-forward

  • Bandwidth :

    24 Gbps

  • Packet forwarding rate :

    8.93Mpps (64 byte packet size)

  • MAC address database size :

    4K (48-bit MAC ad-dresses)

  • Jumbo frame support :

    Up to 9K packet size

  • Mean Time Between Failures :

    126,320 hours (MTBF) @ 25°C

  • 100M Copper Latency :

    8.312µs; 8.412µs; 8.456µs (64-byte; 1518-byte; 9216-byte frames)

  • 1G Copper Latency :

    3.515µs; 3.546µs; 3.624µs (64-byte; 1518-byte; 9216-byte frames)

  • 1G Fiber Latency :

    2.983µs; 3.113µs; 3.161µs (64-byte; 1518-byte; 9216-byte frames)

  • IEEE Network Protocols :

    *

  • Protocols :

    • IEEE 802.3 Ethernet • IEEE 802.3u 100BASE-T • IEEE 802.3ab 1000BASE-T • IEEE 802.3z Gigabit Ethernet 1000BASE-SX/LX • IEEE 802.3af PoE • IEEE 802.3at PoE+ • IEEE 802.3az Energy Efficient Ethernet (EEE) • IEEE 802.3x Full-Duplex Flow Control

  • Monitoring :

    *

  • LEDs :

    Yes

  • Per port :

    Speed, Link, Activity; PoE in different mode

  • Per device :

    Power

  • Physical Specifications :

    *

  • Dimensions (Width * Depth * Height) :

    202 x 140 x 44.5mm (7.95 x 5.51 x 1.75 in)

  • Weight :

    0.95 kg (2.09 lb)

  • Power Consumption :

    65W (when all ports used, line-rate traffic and max PoE)

  • Max power :

    7W (worst case, all ports used, full PoE, line-rate traffic) (Watts)

  • Iddle power consumption :

    5W (all ports link-down standby) (Watts)

  • Energy Efficient Ethernet (EEE) :

    Yes (deactivated by default)

  • Fan :

    Fanless

  • Environmental Specifications :

    *

  • Operating Temperature :

    -20° to 50°C (-4° to 122°F)

  • Operating Humidity :

    90% maximum relative humidity (RH), non-condensing

  • Operating Altitude :

    10,000 ft (3,000 m) maximum

  • Storage Temperature :

    –20° to 70°C (– 4° to 158°F)

  • Storage Humidity (relative) :

    95% maximum relative humidity, non-condensing

  • Storage Altitude :

    10,000 ft (3,000 m) maximum

  • Electromagnetic Emissions and Immunity :

    *

  • Certifications :

    CE mark, commercial; FCC Part 15 Class A, VCCI Class A; Class A EN 55022 (CISPR 22) Class A; Class A C-Tick; EN 55024; CCC; 47 CFR FCC Part 15, SubpartB, Class A ICES-003: 2016 Issue 6, Class A; ANSI C63.4:2014; IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013

  • Safety :

    *

  • Safety Certifications :

    CB mark, commercial; CSA certified (CSA 22.2 #950); UL listed (UL 1950)/cUL IEC 950/EN 60950; EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013 IEC 60950-1:2005; (ed.2)+A1:2009+A2:2013; AN/NZS 60950.1:2015; CCC (China Compulsory Certificate)

  • Warranty and Support :

    *

  • Hardware Limited Warranty :

    Limited Lifetime*

  • Technical Support via Phone and Email* :

    Limited Lifetime*

  • 24x7 Online Chat Technical Support :

    Limited Lifetime*

  • Package Contents :

    *

  • All models :

    Smart Switch; AC Power cord with C13 connector (localized to region of sale) ; Rubber protection caps, which are already installed in the SFP sockets Installation guide

  • Business Type :

    Commercial

  • Bandridth :

    1G

  • More Filters :

    Unmanaged

Questions & Answers



Q: How does the gigabit optical port benefit the switch?

A: The gigabit optical port enables long-distance, high-speed fiber optic connections, ideal for extending the network reach and integrating with existing fiber network infrastructure.



Q: Can the two optical ports be used simultaneously?

A4: Yes, both the optical ports can be used simultaneously, providing flexible uplink options to ensure continuous network connectivity.



Q: What is the maximum power output per PoE port?

A: Each PoE port typically delivers up to 30W of power, compliant with IEEE 802.3at (PoE+), supporting the power needs of various PoE-enabled devices.
