8 Ports 10/100M PoE+ Switch Unmanaged, with 2 Gigabit RJ45 Uplink, with 1 Gigabit SFP, 8 PoE+ Ports@120W Power Budget, 250m PoE+ Extend, Desktop, Fanless, SP5200-8PFE2GE1GF

unmanaged poe switch 8 port
8 port poe switch with sfp module
8 port poe switch with SFP
8 port poe switch with fiber uplink

8 Ports 10/100M PoE+ Switch Unmanaged, with 2 Gigabit RJ45 Uplink, with 1 Gigabit SFP, 8 PoE+ Ports@120W Power Budget, 250m PoE+ Extend, Desktop, Fanless, SP5200-8PFE2GE1GF

Inquire Now

Designed for IP Camera/Wireless Access Point

Product Highlights
    • 8 ports supporting PoE+ to PD device(Like:IP Camera,Wireless AP, VOIP etc.)
    • Complies with IEEE 802.3af/at Power over Ethernet end-span
    • Supports PoE power up to 30 watts for each PoE port
    • 112-watt PoE budget,120-watt total power budget
    • Supports "Default" and "Extend" mode selection;
    • Supports 25-watt PoE transmit distance of 250m and VLAN isolation
    • Auto detects powered device (PD)
    • Supports contact discharge of ±4KV DC and air discharge of ±6KV
    • DC for Ethernet ESD protection
    • Backplane bandwidth 7.6Gbps，Packet forwarding rate 5.66Mpps，MAC address 4k
    • Desktop palm size，Internal AC power supply

Unmanaged 8 port 10/100M PoE Switch authentication

Overview



SP5200-8PFE2GE1GF, 8 Ports 100M Unmanaged PoE+ Switch，with 2 x 1Gb RJ45 Uplink，with 1 x 1Gb SFP，8 x PoE+ Ports@120W power budget,250m PoE+ Extend,Desktop,Fanless

Benchu group’s 8 Port 10/100M Unmanaged PoE+ Switches SP5200-8PFE2GE1GF offers a simple, cost-effective and non-blocking wire-speed performance. The PoE Swtiches provides eight 30-watt 802.3at PoE+ ports ,dual Gigabit RJ45 and 1 Gigabit SFP uplink. Its transmission capacity is more than enough for those network applications with Fast Ethernet speed transmission， And low-cost than the Gigabit switch。The 8 Port 10/100M Unmanaged PoE Switch is ideal for small businesses and workgroups making the deployment of the PoE facility including wireless access points, IP-based surveillance camera and IP phones and door phone in any places easier, more efficient and more cost-effective.



Physical Port

  • 8-10/100Mbps Fast Ethernet ports
  • 2-10/100/1000Mbps Gigabit Ethernet port
  • 1-1.25Gbps mini-GBIC SFP interface



Power over Ethernet

  • 8 ports supporting PoE to PD device (Port 1 to port 8)
  • Complies with IEEE 802.3af/at Power over Ethernet end-span
  • Supports PoE Power up to 30 watts for each PoE port
  • 112-watt PoE budget / 120-watt total power budget
  • The “Extend” mode features 30-watt PoE transmit distance of 250m at speed of 10Mbps and VLAN isolation
  • Auto detects powered device (PD)
  • Circuit protection prevents power interference between ports
  • Remote power feeding up to 100m in standard mode

Switching

  • Hardware-based 10/100/1000Mbps auto-negotiation and auto MDI/MDI-X
  • Flow control for full duplex operation and back pressure for half duplex operation
  • Integrates address look-up engine, supporting 4K absolute MAC addresses
  • Automatic address learning and address aging



Hardware

  • Desktop palm size
  • LED indicators for PoE ready/activity and LINK/ACT
  • Fanless design
  • Internal AC power supply
  • Supports Energy-Efficient Ethernet (EEE) function (IEEE 802.3az)





Features



Fast Port and gigabit port and fiber Port Configuration

8 × PoE+ 10/100Mbps RJ45 ports provide up to 30W per port and total Power budget of 120W, together with 2 × 10/100/1000M RJ45 for uplink connections,with 1 x 1.25G SFP Fort to extend the network transmission distance.

8 port 10/100m poe switch with 1 gigabit sfp



Two Gigabit RJ45 and 1Gigabit SFP Uplink

The SP5200-8PFE2GE1GF with two uplink ports with 10/100/1000Mbps transfer rate to ensure high-speed data and video transmission, reliable assurance for connection between the surveillance system and outside network where the eight PoE+ ports can be used to their full potential.Fiber-Optic Link Capability Enables Extension of Network Deployment，The distance can be extended from 550 meters to 2 kilometers (multi-mode fiber) and 10/20/30/40/50/60/70/120 kilometers (single-mode fiber). They are well suited for applications to uplink to backbone switch and monitoring center in long distance.



8 port poe switch with fiber uplink





Enhanced Flexibility and Deployment Options

The SP5200-16PFE2GE1GF 250-meter PoE switch offers enhanced flexibility in network design, accommodating diverse deployment scenarios that are not feasible with standard 100-meter PoE limitations. This flexibility is crucial for applications requiring distant device placement, such as remote surveillance, extended outdoor Wi-Fi coverage, and large-scale IoT sensor networks. By supporting longer distances, the switch allows for strategic device positioning to optimize coverage and performance. This adaptability ensures that network planners can meet specific environmental and operational needs, improving overall network efficiency and effectiveness while supporting a wider range of use cases.

8 port poe sfp switch 250metre





Reliable Performance in Harsh Conditions

PoE switches with a wide temperature range of -20°C to 50°C ensure reliable operation in extreme weather conditions. This capability makes them ideal for environments where temperatures can fluctuate significantly. Their robust design minimizes the risk of failure due to temperature-related stress, ensuring continuous power and data transmission. This reliability is crucial for maintaining network connectivity in critical applications, such as surveillance systems, remote sensors, and outdoor wireless access points, providing peace of mind that the network will remain operational regardless of environmental conditions.



8 port poe switch with SFP wide temperature







4KV Lightning Protection design Reduced Maintenance Costs

The SP5200-8PGE2GF PoE Switches with 4KV lightning protection require fewer maintenance interventions due to their enhanced resilience against electrical surges. This protection lowers the incidence of surge-related damage, reducing the need for frequent repairs or replacements of damaged equipment. Consequently, maintenance costs are significantly reduced, as less time and resources are spent on addressing surge-related issues.  This reduction in maintenance demands also minimizes network downtime, contributing to overall operational efficiency protecting user investment.



8 port 10/100m poe switch with 1 gigabit sfp Lightning Protection







Connectivity Solutions



8 port 10/100M PoE switch with SFP Uplink of Perfectly-integrated Solution for PoE IP Camera



8 port 10/100M PoE Switch with SFP uplink of Connectivity solutions for IP camera





Specification



  • Technical Specifications :

    SP5200-8PFE2GE1GF

  • 10M/100M RJ45 copper ports :

    8

  • 10M/100M/1G RJ45 copper ports :

    2

  • 1.25G SFP (fiber) ports :

    1

  • Power over Ethernet :

    *

  • PoE Standard :

    IEEE 802.3at Power over Ethernet Plus/PSE； Backward compatible with IEEE 802.3af Power over Ethernet

  • PoE Power Supply Type :

    End-span: 1/2 (+), 3/6 (-)

  • PoE Power Output :

    Per port 52V DC, 300mA. max. 15.4 watts (IEEE 802.3af)； Per port 52V DC, 600mA. max. 30 watts (IEEE 802.3at)

  • PoE Power Budget :

    112 Watts

  • Number of PDs, 7 watts :

    8

  • Number of PDs, 15 watts :

    7

  • Number of PDs, 30 watts :

    3

  • Performance Specification :

    *

  • Chip :

    Realtek

  • Packet buffer memory :

    1.2 Mb

  • Forwarding modes :

    Store-and-forward

  • Bandwidth :

    7.6 Gbps

  • Packet forwarding rate :

    5.66Mpps (64 byte packet size)

  • MAC address database size :

    4K (48-bit MAC ad-dresses)

  • Jumbo frame support :

    9K

  • Mean Time Between Failures :

    110,003 hours (MTBF) @ 25°C

  • 100M Copper Latency :

    8.521µs; 8.622µs; 8.735µs

  • 1G Copper Latency :

    3.443µs; 3.552µs; 3.633µs

  • 1G Fiber Latency :

    2.995µs; 3.113µs; 3.181µs

  • IEEE Network Protocols :

    *

  • Protocols :

    • IEEE 802.3 Ethernet • IEEE 802.3u 100BASE-T • IEEE 802.3ab 1000BASE-T • IEEE 802.3z Gigabit Ethernet 1000BASE-SX/LX • IEEE 802.3af PoE • IEEE 802.3at PoE+ • IEEE 802.3az Energy Efficient Ethernet (EEE) • IEEE 802.3x Full-Duplex Flow Control

  • Monitoring :

    *

  • LEDs :

    Yes

  • Per port :

    Speed, Link, Activity; PoE in different mode

  • Per device :

    Power

  • Physical Specifications :

    *

  • Dimensions (Width * Depth * Height) :

    202 x 140 x 44.5mm (7.95 x 5.51 x 1.75 in)

  • Weight :

    1.1 kg (2.53 lb)

  • Power Consumption :

    120W

  • Max power :

    8W

  • Iddle power consumption :

    5W

  • Energy Efficient Ethernet (EEE) :

    Yes (deactivated by default)

  • Fan :

    Fanless

  • Environmental Specifications :

    *

  • Operating Temperature :

    -20° to 50°C (-4° to 122°F)

  • Operating Humidity :

    90% maximum relative humidity (RH), non-condensing

  • Operating Altitude :

    10,000 ft (3,000 m) maximum

  • Storage Temperature :

    –20° to 70°C (– 4° to 158°F)

  • Storage Humidity (relative) :

    95% maximum relative humidity, non-condensing

  • Storage Altitude :

    10,000 ft (3,000 m) maximum

  • Electromagnetic Emissions and Immunity :

    *

  • Certifications :

    CE mark, commercial； FCC Part 15 Class A, VCCI Class A； Class A EN 55022 (CISPR 22) Class A； Class A C-Tick； EN 55024； CCC； 47 CFR FCC Part 15, SubpartB, Class A ICES-003: 2016 Issue 6, Class A； ANSI C63.4:2014； IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013

  • Safety :

    *

  • Safety Certifications :

    CB mark, commercial； CSA certified (CSA 22.2 #950)； UL listed (UL 1950)/cUL IEC 950/EN 60950； EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013 IEC 60950-1:2005 ；(ed.2)+A1:2009+A2:2013； AN/NZS 60950.1:2015； CCC (China Compulsory Certificate)

  • Warranty and Support :

    *

  • Hardware Limited Warranty :

    Limited Lifetime*

  • Technical Support via Phone and Email* :

    Limited Lifetime*

  • 24x7 Online Chat Technical Support :

    Limited Lifetime*

  • Package Contents :

    *

  • All models :

    Smart Switch； AC Power cord with C13 connector (localized to region of sale) ； Brackets and screws for rack mounting； Rubber protection caps, which are already installed in the SFP sockets Installation guide

  • Business Type :

    Commercial

  • Bandridth :

    100M+1G

  • More Filters :

    Unmanaged



Questions & Answers

Q1: What is the maximum power output per port on the SP5200-8PFE2GE1GF PoE switch?
A1: Each of the 8 PoE ports can deliver up to 30W of power, compliant with IEEE 802.3at (PoE+), suitable for powering devices such as IP cameras, wireless access points, and VoIP phones.

Q2: Can the Gigabit RJ45 ports and SFP Ports be used simultaneously?
A2: Yes, the two Gigabit RJ45 ports and SFP port can be used for connections simultaneously, providing high-speed data transfer to the core network or other switches, ensuring efficient network traffic management.

Q3: What is the purpose of the Gigabit SFP port?
A3: The Gigabit SFP port allows for fiber optic connections, providing extended range and high-speed connectivity to other network devices, which is ideal for long-distance data transmission and network backbone integration.

Q4: Is the switch suitable for both small and medium-sized networks?
A4: Yes, the switch is ideal for small to medium-sized networks, offering 8 PoE ports for device connectivity and additional Gigabit RJ45 ports and Gigabit SFP Port for high-speed uplinks, making it versatile for various network setups.
